Creative Brief


SC Filtration Flyer

SC Filtration

Industrial Sized Dewaxing and Filtration Equipment

Text:
(Front Page)
Filter Trolleys (Picture)
This is a complete filtering funnel (similar in application to a laboratory Buchner Funnel) mounted on a trolley. You can filter solids, waxes, carbon, clay, etc... with these filters. Filter in minutes what you would normally do in hours.
This is a Polypropylene molded plastic filter trolley. This machine is tough, durable and almost indestructible (its basically one solid piece of plastic). PP is impervious to Nitric, Hydrochloric and similar acids so it will easily handle Ethanol, Isopropyl and any solvent you can throw at it.
This machine comes with an included diaphragm pump which does the job of sucking the filtrate through the filter, so NO VACUUM PUMP REQUIRED. The pump can handle acids, bases and alcohols so no special care is needed for this pump. NO COLD TRAP REQUIRED. This is a pneumatic pump so there is no risk of sparks, this means you must supply this machine with compressed air. NO ELECTRICITY REQUIRED.
Filter paper is placed over a removable grate, a seal is then placed around the filter to prevent leaks. This takes a few seconds to install and even faster to take apart. This is an important feature other filters lack, you will find our filters more efficient and convenient.
This machine completely dissembles so is easy to clean.
It comes mounted con casters so it is easily movable.
Benefits:
• Huge filtering area
• Large fluid reservoir
• Fast filtration speed
• No Vacuum Pump required
• No Cold Trap required
• No source of sparks so no explosion risk
• Easy to clean
• Gasketed filter paper for zero leaks
• Inexpensive filter paper
• Filter out carbon, clay, wax, etc...
• Lid helps minimize evaporation
• Easy to move


3 Models Available:
Diameter: 400mm (15.7 inches)630mm (24.8 inches) 800mm (31.4 inches)
Height Minimum: 400mm 550mm 550mm
Capacity: About 9 Gallons Total About 63 Gallons Total About 84 Gallons Total
Material: PP PP PP
Compressed Air Pressure: From 4 to 8 bar (60 to 115 PSI)
Absolute Pressure Minimum: 0.2 bar (0.2 PSI)
Compressed Air Pressure Consumption: From 150 to 420 l/min (14.8 CFM)
Recommended Compressor: 5HP 17.9 CFM at 100 PSI
Made in Italy
Base Price: $4,500.00 $5,000.00 $8,000.00

Back Page:

Filter Press for Dewaxing and General Filtration
Custom filter press for polishing up Oleoresins dissolved in a solvent. There is no faster or more convenient way to filter your solution than a filter press.
This machine is the critical step missing in your MIPs lab between your initial extraction (Ethanol, CO2, Butane) and your Rotary Evaporator. No more filtering by hand. No more small Buchner funnels.
Whether you have a resin made with CO2, Butane, Propane or other gases, solvents such as Ethanol or others, this unit will work for your oil. Your oleoresin must be dissolved in a solvent like ethanol, isopropanol, and methanol.
System includes a recessed plate filter press which you can customize the number of filter plates and thus the filtration capacity of the unit. Unit can hold up to one cubic feet (larger units available). This means you can hold up to 28 liters of filter cake, wax, clay, spent carbon, silica, magsil, etc...
Our press is designed with an air bleed system so you can clear out all your solution from the press and filtration media so in the end there is no waste from soaked clay or carbon or lots of solution in your pipes or equipment.
This easy to use unit will filter out particles from your solution, such as dirt, leaves, soil, carbon, clay, etc... After initial filtration, you can use this unit to de-wax your cold solution.
It includes everything needed to get you going (you must supply compressed air and electricity), including consumables, operating instructions and support.
All valves and plumbing are included and we use cam and grove fittings and sanitary fittings so this unit is easy to disassemble and clean or unplug pipes to move it around. We know how nasty and sticky oleoresins are so this machine breaks down quickly and completely so you can clean every nook.
Unit includes a diaphragm pump with Teflon diaphragms that are inert to your solution and tough enough to last for months of service. The diaphragms will work hot or cold, and can take large particles without getting clogged or damaged. Diaphragm pumps are easy to use and easy to regulate the speed they operate at, are easy to clean and disassemble, and are easy to repair with easy to source replacement parts. These pumps are powered by air, thus eliminating the risk of an explosion caused by sparks in an electric motor. Our pump does not have to be primed, so it can suck the solution as well as pump it at high pressures.
Benefits of this system:
• Labor savings.
• Can Filter, de-wax, bleach, deodorize, and clarify.
• Solvent savings.
• Time savings.
• Safe and easy to use.
• Quick and easy to clean.
• Closed Loop System
• Multi-function unit.
• Fast filtering.
• Made in the USA

2 in 1 Drying Filter Press
Combo filter press for drying and filtering biomass.
Feed this unit directly from your solvent based extraction vessel thus separating the biomass from the solvent all in one step. The end result is a filtered solvent ready for post processing. Your biomass will be dry and easily disposable.
This unit does the job of a centrifugal dryer and a filter, all in one machine and one single step. This allows you to keep your extraction, filtration and drying all in one closed loop system.
This unit is safe to operate with any solvent including ethanol, methanol, isopropanol, etc...
You must have a properly agitated extraction vessel, extracting using a solvent. Your biomass must be debucked to remove fiber and make pumping easier. Your biomass must be ground, making extraction more efficient and pumping easier.
The machine operates with an air powered pump that sucks your biomass slurry directly from your extraction vessel into the filter press. The press separates your biomass from the solvent and filters solvent so you can proceed to dewaxing if necessary, or other post processing like carbon or clay scrubbing and eventual solvent recovery.
When you have recovered all biomass from your extraction vessel, pumping is stopped and a series of bladders squeeze the biomass to remove any excess solvent. All solvent that leaves the press is simultaneously filtered. The end result is a biomass brick that has little moisture. The press is opened, the biomass cake falls into a dumpster and is ready to be discarded or composted.
There is no use of filter bags from your reactor, your solution is pumped directly into the press.
Filter Press is FDA compliant with special “thread less steel manifold” and vegetable oil hydraulics and cylinder. Each component on the filter press follows FDA guidelines, but the filter press itself cannot be FDA certified despite all components following the guidelines.
Order includes a recessed plate filter press which you can customize the number of filter plates and thus the filtration capacity of the unit. Unit can hold up to five cubic feet (larger units available). This means you can hold about 50 pounds of filter cake.
Our press is designed with an air bleed system so you can clear out all your solution from the press and filtration media so in the end there is no waste from soaked clay or carbon or lots of solution in your pipes and filter press.
This easy to use unit will filter out particles from your solution, such as dirt, leaves, soil, carbon, clay, etc...
After initial filtration, you can use this same unit to de-wax your cold solution. We use plastics for our plates so there is less thermal transfer making this a perfect dewaxing machine.
Benefits of this system:
• Can dry, filter, de-wax, bleach, deodorize, and clarify.
• Labor savings.
• Solvent savings.
• Time savings.
• Safe and easy to use.
• Quick and easy to clean.
• Multi-function unit.
• Fast filtering.
• Made in the USA

Agriculture

Industrial Customers. This is a technical brochure.

8.5" x 11" double sided.
300dpi CMYK images
